Specifications

• Air throughput with max. duct diameter in vented mode (not for external version) -
  • Air throughput and sound emissions: Values upon request
• Control panel -
  • Slide switch: The sealed, smooth surface prevents contact with the electrical components/motor.
  • Recessed knob controls: •
• Design -
  • Color: Stainless steel
• Installation notes -
  • Vent connection at top: •
  • Installation template: •
  • Diameter of vent connection in in.(mm): 6 (150)
• Lighting -
  • LED ClearView lighting: With up to 4.5 W they illuminate the cooktop with a warm light.
  • Light intensity in Lx: 275
  • Color temperature in K: 3,000
• Operating modes -
  • Recirculated mode: Convertible
• smooth surface prevents contact with the electrical components/motor. }, Filter system -
  • Dishwasher-safe stainless steel grease filters: 3
• Standard accessories -
  • Non-return flap: •Non-return flapA non-return flap is supplied with every appliance and prevents the backflow of cold and/or warm outside air with vented mode ventilation hoods. This component is installed in the exhaust socket above the motor in your ventilation hood and prevents air from flowing back through the vented ducting when the appliance is not in use.
  • Recirculation deflector: •Recirculation deflectorThe diectional unit is fitted at the top of the ventilation hood tower and directs the air back into the kitchen through the grilles in the tower. A special feature of the Miele directional unit for island ventilation hoods is that air is expelled from all four sides. This lowers the air flow velocity and in so doing reduces noise levels.
• Technical data -
  • Standard plug fitted: •
  • Fuse rating in A: 15
  • Number of phases: 1
  • Height of hood canopy in in.(mm): 5 (125)
  • Length of electrical wire in ft (m): 4 (1.5)
  • Total connected load in kW: 0.29
  • Depth of hood canopy in in.(mm): 19 3/4 (500)
  • Net weight in lbs. (kg): 29 (12.9)
  • Canopy width in in.(mm): 30 (760)
  • Voltage in V: 120
• 000 }, Blower -
  • AC motor: •
  • Single-action blower: •
• Blower
  • Single-action blower
  • AC motor
• Cleaning convenience
  • EasyClean CleanCover hood liner
• Construction type
  • Built-under ventilation hood
• Construction type -
  • Built-under ventilation hood: •
• Control Panel
  • Recessed knob controls
  • Slide switch
  • Power levels (number excl. Intensive):3
  • Intensive setting
• Design
  • Color :Stainless steel
• Filter System
  • Dishwasher-safe stainless steel grease filters :3
• Installation Notes
  • Vent connection at top
  • Diameter of vent connection in in.(mm) :6 (150)
  • Installation template
• LIGHTING
  • Light intensity in Lx :275
  • Color temperature in K :3,000
  • LED ClearView lighting
• Operating modes
  • Recirculated mode :Convertible
• Standard accessories
  • Non-return flap
  • Recirculation deflector
• Technical Data
  • Canopy width in in.(mm) :30 (760)
  • Height of hood canopy in in.(mm) :5 (125)
  • Total connected load in kW :0.29
  • Voltage in V :120
  • Number of phases :1
  • Depth of hood canopy in in.(mm):19 3/4 (500)
  • Net weight in lbs. (kg) :29 (12.9)
  • Length of electrical wire in ft (m) :4 (1.5)
  • Standard plug fitted
  • Fuse rating in A :15

Description

Features

• Miele CleanCover:Convenience and safety in detail
• Miele's unique easy cleaning: The sealed, smooth surface prevents contact with the electrical components/motor.
• Stainless-steel grease filters (10-layer):Efficient in extracting steam, The high-quality metal grease filters are dishwasher-safe and extremely durable.
• Design variety:Clear design, intelligent technology: you can choose between many models and features.
• LED ClearView Lighting:Environmentally friendly and long lasting: With up to 4.5 W they illuminate the cooktop with a warm light.
• Miele CleanCover:Miele's unique easy cleaning: The sealed, smooth surface prevents contact with the electrical components/motor.
• Active AirClean filter:Efficient in absorbing odors: In recirculation mode odors are absorbed and neutralized completely.
• Handcrafted in Germany:Know-how and craftsmanship: Our expertise goes into every ventilation hood, from development to finished product.
• Perfect craftsmanship:Unique characteristics of Miele hoods: precise contours and precision joints.
